MEDICAL DOOR
Aiming at the special structure design of hospital, Keer provides a full range of personalized design to meet the different requirements for clean zones, wards, public areas and the personalized needs for patients and visitors.
Hermetic automatic doors apply to hospital operation room, electronic workshop, etc. where specially has high sealing requirements. DEPER hermetic doors have the high performance and both positive pressure (pressure increase) and negative pressure (pressure decrease) can show the same performance. Microcomputer controller is combined with foot inductive switch or palm inductive switch, health care personnel stretches his/her foot into induction box or puts hand near to the sensor, automatic door will open. Non-contact switch mode is free from being polluted. Two-way magic eyes detect the automatic door during closing offers security to pass through.
TECHNICAL DATA
Door configuration： Single leaf
Limited Weight： ≤150kgs
Clean open width： 2000(W) X 2500(H)
Power voltage： AC 110V-220±10%, 50/60Hz
Power consumption： <100W
Opening speed： 200-500mm/S(adjustable)
Closing speed： 200-500mm/S(adjustable)
Hold-open time： 0-9S(adjustable)
Manual force： <100N
Opening control： foot inductive switch/ palm inductive switch
Closing control： Auto/Signal
